QC3.0充電管理IC: uP9616
UP9616是一個(gè)電源管理IC，符合QC3.0,FCP,QC2.0,Apple,BC1.2,Samsung充電協(xié)議。輸入8V-32V，輸出3.6-12V/3.3A。封裝樣式VDFN6*5-8L、VDFN5*6-10L。適用于旅行充電器，車載充電器。FeatureWideInputVoltageRange:4.5Vto32VOutputVoltageRange:0.613Vt
- 型號： uP9616
UP9616是一個(gè)電源管理IC，符合QC3.0,FCP,QC2.0,Apple,BC1.2,Samsung充電協(xié)議。輸入8V-32V，輸出3.6-12V/3.3A 。封裝樣式VDFN6*5-8L、VDFN5*6-10L 。適用于旅行充電器，車載充電器。
Feature
Wide Input Voltage Range: 4.5V to 32V
Output Voltage Range: 0.613V to 5.5V
Wide Output Load Range: 0A to 7A
Built-In 1% 0.613V Reference
Built-In LDO Linear Voltage Regulator
RCOTTM (Robust Constant On-Time) Control Architecture
4 Selectable Frequency Setting
4700ppm/°C RDS(ON) Current Sensing
0.6ms, 1.2ms, 2.4ms and 4.8ms Selectable Internal Voltage Soft-Start
Pre-charged Start-up Capability
Built-in Output Discharge
Built-in OVP/UVP/OCP/OTP
WQFN4x4-32L Package
RoHS Compliant and Halogen Free
Application
Portable Charging Devices
Point-of-Load Systems
Notebook Computers
I/O Supplies
System Power Supplies
